Thaum xaiv Q310NH Corten Steel rau tej yaam num-txawm yog kev tsim, architectural, los yog vaj siv- nkag siab txog nws lub zog tawm los yog qhov tseem ceeb rau kev ruaj ntseg thiab kev ua haujlwm. Ntau tus neeg yuav khoom thiab cov neeg tsim khoom xav tsis thoob: Dab tsi yog nws lub zog tawm los? Tus lej ntawd txhais li cas rau kev siv tswv yim? Nws piv rau lwm qib Corten li cas? Lub ntsiab lus teb yog qhov tseeb:Qhov tsawg kawg nkaus yield zog ntawm Q310NH Corten Steel yog 310 megapascals (MPa) - nruab nrab - lub luag hauj lwm ntsuam xyuas uas sib npaug zog thiab formability rau feem ntau lub teeb - rau - nruab nrab tej yaam num. Hauv qab no yog cov lus qhia luv luv, cov tswv yim qhia txog qhov no txhais tau li cas rau koj.
Ua ntej: Dab tsi yog Yield Strength (Piv txwv yooj yim)
Lub zog tawm los yog lub zog ntawm lub zog ( ntsuas hauv MPa) cov khoom tuaj yeem tiv taus ua ntej nws khoov lossis deforms mus tas li [superscript:1]. Rau Q310NH, qhov no txhais tau tias:
Nws tuaj yeem tswj tau txog li 310MPa ntawm kev ntxhov siab yam tsis tau poob nws cov qauv qub - tseem ceeb rau cov khoom siv uas yuav tsum tau nyob ruaj khov.
Tsis zoo li lub zog tensile (uas ntsuas qhov taw tes tawg), lub zog tawm los tsom raumus tas li deformation- yog ib qho tseem ceeb rau kev zam qhov project tsis ua hauj lwm.
Q310NH Yield Strength: Cov Lus Qhia Tseem Ceeb & Cov Qauv
Q310NH's yield zog tsis yog arbitrary- nws tau txhais los ntawm kev lag luam qauv thiab khi rau nws muaj pes tsawg leeg:
Yam tsawg kawg nkaus Yield Strength310MPa (yuav tsum tau ib GB / T 4171, tus qauv tseem ceeb rau huab cua hlau). Qee tus neeg xa khoom tuaj yeem tsim nws nrog lub zog siab dua me ntsis (320-340MPa), tab sis 310MPa yog qhov lav qhov tsawg kawg nkaus.
Vim li cas "310" hauv Q310NH?: "310" nyob rau hauv nws qib ncaj qha hais txog nws qhov tsawg kawg nkaus yield zog (310MPa)- ib qho kev sib koom naming convention rau steel qib, qhov twg tus lej tom qab "Q" (luv rau "yield" hauv Suav qauv) qhia tias muaj zog yield [superscript:1].
Tensile Strength Cov ntsiab lus: Nws ua ke nrog lub zog tensile ntawm 450-600MPa, txhais tau tias nws tuaj yeem tiv taus ntau dua ua ntej tawg - txhawb nqa nws txoj kev ntseeg siab rau kev siv lub teeb pom kev zoo.
Tswv yim cuam tshuam: 310MPa txhais li cas rau koj qhov project
Lub zog 310MPa yield ua rau Q310NH zoo tagnrho rau kev siv tshwj xeeb- ntawm no yog yuav ua li cas nws txhais ua tiag - ntiaj teb daim ntawv thov:
Zoo tagnrho rau lub teeb-rau- Nruab nrab Loads: Zoo meej rau guardrails, me me thav duab, facade cladding kev txhawb nqa, thiab vaj trellises - muaj zog txaus los tuav lub teeb loads yam tsis muaj dabtsi yog khoov.
Tsis yog rau Hnyav Loads: Tsis txhob siv nws rau cov khoom siv hnyav (piv txwv li, cov txuas hniav loj, cov phab ntsa tuav)-cov no yuav tsum muaj zog ntau dua (Ntau dua lossis sib npaug rau 355MPa, xws li Q355GNH).
Sib npaug ntawm lub zog & Formability: Tsis zoo li siab -yield steel (uas yog nruj), Q310NH's 310MPa qhov ntsuas ua kom nws tsim tau yooj yim -yooj yim khoov, txiav, thiab zoo li tus qauv tsim.
Q310NH vs. Lwm Corten Steels (Yield Strength piv)
Txhawm rau muab 310MPa hauv kev xav, muab piv rau Corten qib:
Q265GNH (Lub Teeb-Lub Luag Haujlwm): 265MPa yield zog-tsis muaj zog dua Q310NH, zoo dua rau kev siv tsis yog- qauv / kho kom zoo nkauj (xws li cov cog me me).
Q310NH (nruab nrab-Lub luag haujlwm): 310MPa- sib npaug lub zog thiab formability rau feem ntau cov haujlwm.
Q355GNH (High-Lub Luag Haujlwm): 355MPa- muaj zog dua, rau kev siv cov qauv hnyav tab sis tsawg formable thiab kim dua.
Nyob rau hauv luv luv, Q310NH Corten Steel muaj qhov tsawg kawg nkaus yield zog ntawm 310MPa- nruab nrab- lub luag hauj lwm ntsuam xyuas uas ua rau nws siv tau rau lub teeb - mus rau - nruab nrab tej yaam num. Nws lub zog tawm los tau pom meej meej hauv nws qib, thiab nws ua rau qhov sib npaug zoo tshaj plaws ntawm lub zog thiab kev tsim kho rau feem ntau siv Corten Steel.
